Quest 876
High Capacity Series
Model #4037600
@ 80 F | 60% RH
- Capacity 876 Pints/Day
- Efficiency 6.6 Pints/kWh
- Supply Voltage 220-240V
- Current Draw 24.7 Amps
Overview
Powered by patented coil technology that isn’t available anywhere else, the Quest 876 dehumidifier is designed to work round-the-clock with maximum energy efficiency and flexibility. Featuring integrated handles and hang points, this powerhouse machine can be suspended overhead, freeing up valuable floor space.
M-CoRR Technology
The Quest 876 dehumidifier boasts our unique patented M-CoRR technology. This multi-coil refrigeration design recycles excess heat to provide the highest efficiencies available on the market, while reducing heat (BTUs) output into your space.
The Quest 876 is engineered and assembled in Madison, Wisconsin, USA. It’s backed by a 5-year warranty providing confidence in your purchase. In addition, this unit meets California Title 24 requirements for ducted (whole-home) installation.
key features
HIGH EFFICIENCY
Pulling more water per kilowatt hour than any other brand, saving energy and dollars
PATENTED MULTI-COIL TECHNOLOGY
Achieves highest efficiencies
available in the market
INDUSTRY’S LOWEST AMP DRAW
More efficient units have less heat output and free up electricity for other equipment
Features
OVERHEAD OR GROUND PLACEMENT
Built to fit what works for your space
WIDEST OPERATING RANGE
Of temperature and relative humidity
UL RATED AND ETL LISTED
The highest safety standard
INTEGRATED HANDLES
For ease of movement
MERV 13 FILTRATION
Superior filtration removes more harmful contaminants from the air such as dust, pollen and mold as well as bacteria and some viruses
AUTO RESTART
Unit automatically defaults to prior settings in the event of a power outage
Specifications
@ 80 F / 60% RH
Water Removal
876 Pints/Day
Efficiency
6.6 Pints/kWh
Energy Factor
3.1 L/kWh
Current Draw
24.7 Amps
Power
5,500 Watts
BTU (Total)
58,200
BTU (Heat of Condensation)
39,600
BTU (Motor Load)
18,600
@ 75 F / 50% RH
Water Removal
614 Pints/Day
Efficiency
5.2 Pints/kWh
Energy Factor
2.5 Liters/kWh
Current Draw
22.4 Amps
california title 24 compliant
Ducted Energy Factor
6.2 Pints/kWh @ 73 F | 60% RH
Part Number
4037600
Dehumidifier Type
Refrigerant Dehumidifier
CFM
1,850
Operating Temperature
56 F Min–95 F Max
Supply Voltage
220–240 VAC, 1 Phase, 60 Hz
Unit Dimensions
44.8″ L x 28.9″ W x 34.1″ H
Unit Weight
350 lb
Control Type
Requires external control
Air Filter MERV Rating
MERV 13
Air Filter Dimensions
18″ x 20″ x 2″
Power Cord
Hardwire Only
Refrigerant Type
R410A
Refrigerant Amount
6 lb 4 oz
Drain Port Connection
3/4″ Threaded NPT
Warranty
5 Year
Installation Options
Freestanding unit
Can be mounted overhead with use of 3/8″ Threaded Rod
P-Trap Requirements
