Quest 335 208/230V
HIGH-EFFICIENCY SERIES
Model #4046200
@ 80 F | 60% RH
- Capacity 345 Pints/Day
- Efficiency 8.0 Pints/kWh
- Supply Voltage 208-230V
- Current Draw 8.4A @208V / 7.6A @230V
Overview
The Quest 335 208/230V dehumidifier is engineered specifically for commercial spaces facing a heavy moisture load, like indoor agriculture and water treatment facilities. At the core of Quest’s 335 features are our sophisticated refrigeration system, M-CoRR Technology, and digital controls with the versatility to work with external controls.
In addition to industry-leading MERV-13 filtration, the 335 features Quest’s filter compensation technology, which increases fan speed as the filter becomes increasingly clogged with pollen, powdery mildew, dust, and dirt. This speed adjustment with static pressure changes allows for the same amount of air to pass through the filter without reducing the cubic feet for minute (CFM). As a result, the Quest 335 can work consistently and constantly to optimize your environment with maximum energy efficiency and consistency.
Patented M-CoRR Technology
Both Quest 335 units (208/230V and 277V) boast our unique patented M-CoRR Technology. This advanced multi-coil design is similar to the one used in the Quest 506. The end result is 345 pints of water pulled from the air every 24 hours at 80F and 60% relative humidity at an impressive 8 pints/kWh.
All refrigerant dehumidifiers create heat as a byproduct of the dehumidification process. Our multi-coil refrigeration design recycles excess heat to provide the highest efficiencies available on the market, while reducing heat (BTUs) output into your space. When you combine the dollars associated with low energy consumption, reduced air conditioning usage, and a consistent environment to prevent product loss and support product quality, the Quest 335 is one of the most cost-effective units on the market.
The Quest 335 dehumidifier is engineered and assembled in Madison, Wisconsin. It’s backed by a 5-year warranty for after-purchase peace of mind. In addition, this unit meets California Title 24 requirements for both ducted (whole-home) and non-ducted (portable) installations.
Also available in 277V: View Quest 335 277V
Key Features
INDUSTRY’S LOWEST AMP DRAW
More efficient units have less heat output and free up electricity for other equipment
PATENTED MULTI-COIL TECHNOLOGY
Achieves highest efficiencies available in the market
Superior merv-13 filtration
20% more effective in capturing harmful contaminants in the air than MERV-11 and 65% more effective than MERV-8
Features
OVERHEAD OR GROUND PLACEMENT
Built to fit what works for your space
PLUG-N-PLAY
No installation required
HIGH EFFICIENCY
No dehumidifier is more efficient
WIDEST OPERATING RANGE
Of temperature and relative humidity
UL RATED AND ETL LISTED
The highest safety standard
DIGITAL CONTROL
Digital control interface with external control option
INTEGRATED HANDLES
For ease of movement
LONG POWER CORD
For extended reach
AUTO RESTART
Unit automatically defaults to prior settings in the event of a power outage
MERV 13 FILTRATION
Superior filtration removes more harmful contaminants from the air such as dust, pollen and mold as well as bacteria and some viruses
FILTER COMPENSATION TECHNOLOGY
Compensates for increased static pressure due to filters or ducting, providing consistent powerful airflow
PATENTED MULTI-COIL TECHNOLOGY
Achieves highest efficiencies available in the market
Specifications
@ 80 F | 60% RH
Water Removal
345 Pints/Day
Efficiency
8.0 Pints/kWh
Energy Factor
3.8 Liters/kWh
Current Draw
8.4A @208V / 7.6A @230V
Power
1,700 Watts
BTU (Total)
21,500
BTU (Heat of Condensation)
15,700
BTU (Motor Load)
5,800
@ 75 F | 50% RH
Water Removal
221 Pints/Day
Efficiency
6 Pints/kWh
Energy Factor
2.8 Liters/kWh
California title 24 compliant @ 208V / 230V
Non-Ducted Energy Factor
6.2 Pints/kWh @ 65 F | 60% RH
Ducted Energy Factor
7.4 Pints/kWh @ 73 F | 60% RH
Part Number
4046200
Dehumidifier Type
Refrigerant Dehumidifier
CFM
900
Operating Temperature
56 F Min–95 F Max
Supply Voltage
208–230 VAC, 1 Phase, 60 Hz
Unit Dimensions
32.9″ L x 24.6″ W x 23.7″ H
Unit Weight
215 lb
Control Type
Onboard digital controls with low voltage terminal block
Air Filter MERV Rating
MERV 13
Air Filter Dimensions
20″ x 22″ x 2″
Power Cord
14ga NEMA 6-15P (10′)
Refrigerant Type
R454B
Refrigerant Amount
3 lb 8 oz
Drain Port Connection
3/4″ Threaded NPT
Fans
Variable Speed EC Motor
Warranty
5 Year Limited
Sizing & Selection
How to properly size your dehumidification equipment (VIDEO)
How to properly size your dehumidification equipment (VIDEO)
Getting at how much humidity control you need isn’t the international man of environmental control mystery, like many of us think. In fact, how to properly size your dehumidifiers is relatively straightforward IF you have the necessary data.
Read More →
Grow room dehumidifiers: Perfect your setup
Grow room dehumidifiers: Perfect your setup
When the team at East Coast Cultivation set out to build its new indoor grow operation in Rhode Island, it knew it had to nail one thing: environmental controls.
Read More →
Vapor Pressure Deficit and Why it Matters
Vapor Pressure Deficit and Why it Matters
The gardening world is filled with trends and phrases that come and go as quickly as they’re created. Sometimes these concepts are thrown around without full understanding, especially with the more scientific processes. One of the most misunderstood concepts is vapor pressure deficit, or VPD, as it’s commonly called.
Read More →Need Help Sizing?
Our humidity experts are standing by to assist.
Installation Options
Freestanding unit
Can be mounted overhead with use of 3/8″ Threaded Rod
P-Trap Requirements
