Quest 155
High Efficiency Series
Model #4046120
@ 80 F | 60% RH
- Capacity 155 Pints/Day
- Efficiency 8.5 Pints/kWh
- Supply Voltage 110-120V
- Current Draw 6.9 Amps
Quest 155 Overview
Discover the NEW Quest 155 dehumidifier: this compact and efficient model shrinks by 20% compared to its predecessor, the Quest Dual 155, and easily plugs into any standard 120v outlet, making it suitable for any space. Equipped with onboard digital controls, the redesigned Quest 155 offers precise humidity management and self-diagnostics for easy operation. The integrated hang points facilitate straightforward overhead installation without needing an additional hang kit. Additionally, its removable access panel ensures easy maintenance and serviceability, even while hung overhead. Your facility technicians will thank you!
Engineered with Quest’s patented M-CoRR Technology, the Quest 155 delivers superior performance and significantly lowers your utility costs, boasting an impressive efficiency rating of 8.5 pints/kWh at 80°F and 60% RH. Removing 155 pints of water per day at the same conditions, this unit can save you thousands in energy costs, per unit, every year compared to our competitors.
The Quest 155 dehumidifier is engineered and assembled in Madison, Wisconsin. It’s backed by a 5-year warranty. In addition, this unit meets California Title 24 requirements for both ducted (whole-home) and non-ducted (portable) installations.
Key features
plug and play
Utilizes a standard 120V outlet with
easy digital controls
Patented M-CoRR Technology
No dehumidifier is more efficient
LOWEST OPERATIONAL COSTS
Higher efficiency equipment substantially lowers utility costs
Features
OVERHEAD OR GROUND PLACEMENT
Built to fit what works for your space
WIDEST OPERATING RANGE
Of temperature and relative humidity
UL RATED AND ETL LISTED
The highest safety standard
LONG POWER CORD
For extended reach
AUTO RESTART
Unit automatically defaults to prior settings in the event of a power outage
MERV 13 FILTRATION
Superior filtration removes more harmful contaminants from the air such as dust, pollen and mold as well as bacteria and some viruses
DIGITAL CONTROL
Digital control interface with external control option
COMPACT UNIT
For mobility and a small footprint that won’t interfere with operations
ASSEMBLED IN MADISON, WISCONSIN
Built to last.
Specifications
@ 80 F | 60% RH
Water Removal
155 Pints/Day
Efficiency
8.5 Pints/kWh
Energy Factor
4.0 Liters/kWh
Current Draw
6.9 Amps
Power
750 Watts
BTU (Total)
9,700
BTU (Heat of Condensation)
7,100
BTU (Motor Load)
2,600
@ 75 F | 50% RH
Water Removal
90 Pints/Day
Efficiency
5.6 Pints/kWh
Energy Factor
2.6 Liters/kWh
Current Draw
5.7 Amps
California Title 24 compliant
Non-Ducted Energy Factor
6.0 Pints/kWh @ 65 F | 60% RH
Ducted Energy Factor
7.3 Pints/kWh @ 73 F | 50% RH
Part Number
4046120
Dehumidifier Type
Refrigerant Dehumidifier
CFM
500
Operating Temperature
56 F Min–95 F Max
Supply Voltage
110–120 VAC, 1 Phase, 60 Hz
Unit Dimensions
26.8″ L x 23.6″ W x 20.9″ H
Unit Weight
130 lb
Control Type
Digital onboard controls with low voltage terminal block
Air Filter MERV Rating
MERV 13
Air Filter Dimensions
18″ x 18″ x 2″
Power Cord / Plug
14/3, SJTW (9’) / NEMA 5-15P
Refrigerant Type
R454B
Refrigerant Amount
3 lb 0 oz
Drain Port Connection
3/4″ Threaded NPT
Warranty
5 Year Limited
Installation Options
Freestanding
Overhead
P-Trap Requirements
