Quest 205
High Efficiency Dehumidifier Series

Model #4046110

@ 80 F / 60% RH

  • Capacity 200 Pints/Day
  • Efficiency 7.7 Pints/kWh
  • Supply Voltage 110-120V
  • Current Draw 10.0 Amps
Five Year Warranty badge, Engineered and Assembled in Madison, WI badge, and California Title 24 Compliant badge

Quest 205 Overview

Little brother to the well-known Quest 225 and Quest 335, the Quest 205 is Quest’s highest capacity 115V dehumidifier for use in a standard outlet. Using 10 amps, the Quest 205 removes 200 pints of water per day at 80 degrees Fahrenheit and 60% relative humidity, making it even more energy-efficient than its predecessor and its competitors.

Priding itself on innovation, Quest redesigned its 205-pint dehumidifier utilizing its ground-breaking refrigeration design, called M-CoRR™ Technology. This patented new technology has many benefits, but the most notable is that it recycles energy during dehumidification, resulting in a 30% capacity boost. M-CoRR is the secret behind our industry-leading performance and energy efficiency. Learn more about its benefits here.

Easily operate the Quest 205 with onboard digital controls, or connect remotely using its low-voltage terminal block. Simply install the Quest 205 dehumidifier overhead with integrated hang points to free up floor space. Effortlessly remove a side panel to access internal components for cleaning and maintenance, without having to uninstall from the ceiling. Customer feedback is at the core of our product development, resulting in this user-friendly design.

Like all Quest products, the Quest 205 is engineered and assembled in Madison, Wisconsin using the highest quality components and materials available. It’s backed by a 5-year warranty for peace of mind.

M-CoRR

Features

OVERHEAD OR GROUND PLACEMENT

Built to fit what works for your space

PLUG-N-PLAY

No installation required

WIDEST OPERATING RANGE

Of temperature and relative humidity

UL RATED AND ETL LISTED

The highest safety standard

LONG POWER CORD

For extended reach

AUTO RESTART

Unit automatically defaults to prior settings in the event of a power outage

MERV 13 FILTRATION

Superior filtration removes more harmful contaminants from the air such as dust, pollen and mold as well as bacteria and some viruses

DIGITAL CONTROL

Digital control interface with external control option

INTEGRATED HANDLES & HANGING POINTS

For easier movement and installation

Specifications

@ 80 F / 60% RH

Water Removal

200 Pints/Day

Efficiency

7.7 Pints/kWh

Energy Factor

3.6 Liters/kWh

Current Draw

10 Amps

Power

1,100 Watts

BTU (Total)

12,800

BTU (Heat of Condensation)

9,100

BTU (Motor Load)

3,700

@ 75 F / 50% RH

Water Removal

135 Pints/Day

Efficiency

5.4 Pints/kWh

Energy Factor

2.6 Liters/kWh

Current Draw

8.9 Amps

Part Number

4046110

Dehumidifier Type

Refrigerant Dehumidifier

CFM

575

Operating Temperature

56 F Min–95 F Max

Supply Voltage

110–120 VAC, 1 Phase, 60 Hz

Unit Dimensions

26.8″ L x 23.6″ W x 20.9″ H

Unit Weight

130 lb

Control Type

Onboard controls with low voltage terminal block

Air Filter MERV Rating

MERV 13

Air Filter Dimensions

18″ x 18″ x 2″

Power Cord

9′, NEMA 5-15P

Refrigerant Type

R454B

Refrigerant Amount

3 lb 2 oz

Drain Port Connection

3/4″ Threaded NPT

Warranty

5 Year

California Title 24 Compliance

Ducted Energy Factor

6.5 Pints/kWh @ 73 F | 60% RH

Installation Options

Freestanding dehumidifier

Freestanding unit

Overhead deahumidifier

Hanging unit

P-Trap Requirements
