Quest CDG 174

PORTABLE SERIES

@ 80 F / 60% RH

  • Capacity 176 Pints/Day
  • Efficiency 7.7 Pints/kWh
  • Supply Voltage 110–120V
  • Current Draw 10 Amps

Overview

Increase drying and curing times, eliminate mold and mildew, and make the air more comfortable with a Quest portable dehumidifier. With 12-inch recessed wheels and a 25-foot cord, the Quest CDG 174 was engineered for movement and flexibility wherever additional dehumidification is needed. Assembled in Madison, Wisconsin, this efficient dehumidifier on-wheels features an onboard humidistat, an internal condensate pump for easy water transport and a full electronic control panel.

Key Features

PORTABLE COMMERCIAL DEHUMIDIFICATION

The highest capacity portable dehumidifier available on the market

LONG POWER CORD

For extended reach

A small, green box fitting into the corner of a larger box, showing scale.

MOVABLE COMPACT UNIT

Integrated handles for mobility and small footprint won’t interfere with grow room operations

Features

PLUG-N-PLAY

No installation required

WIDEST OPERATING RANGE

Of temperature and relative humidity

INDUSTRY’S LOWEST AMP DRAW

More efficient units have less heat output and free up electricity for other equipment

UL RATED AND ETL LISTED

The highest safety standard

ONBOARD DEHUMIDISTAT

Along with a low voltage terminal block

INTERNAL CONDENSATE PUMP

With detachable hose

AUTO RESTART

Unit automatically defaults to prior settings in the event of a power outage

MERV 11 FILTRATION

Can remove harmful contaminants from the air such as dust, pollen and mold

Specifications

@ 80 F / 60% RH

Water Removal

176 Pints/Day

Efficiency

7.7 Pints/kWh

Energy Factor

3.6 Liters/kWh

Current Draw

10 Amps

Power

1,200 Watts

BTU (Total)

12,000

BTU (Heat of Condensation)

8,000

BTU (Motor Load)

4,000

@ 75 F / 50% RH

Water Removal

116 Pints/Day

Efficiency

4.5 Pints/kWh

Energy Factor

2.1 Liters/kWh

Current Draw

9.3 Amps

Part Number

4031170

Dehumidifier Type

Refrigerant Dehumidifier

CFM

380

Operating Temperature

56 F Min–110 F Max

Supply Voltage

110–120 VAC, I Phase, 60 Hz

Unit Dimensions

23″ W x 40″ H x 20″ L

Unit Weight

135 lb

Control Type

Onboard controls with low voltage terminal block

Air Filter MERV Rating

MERV 11

Air Filter Dimensions

16″ x 20″ x 2″

Power Cord

14ga NEMA 5-15P (10′)

Refrigerant Type

R410A

Refrigerant Amount

2 lb 2 oz

Drain Port Connection

3/4″ Threaded NPT

Warranty

5 Year

Sizing & Selection
