Quest TROTEC TR 190 / 390

TR Series

@ 80 F/60% RH

  • Capacity 190-390 Pints/Day
  • Supply Voltage 380-480V
  • Current Draw 7.5 -15 Amps

Overview

Ideal for light to mid-duty commercial applications, the TR 190 and TR 390 are popular choices for a range of facility types, including natural supplements operations and small food-processing facilities.

Key Features

FLEXIBLE PLATFORM

Ability to switch out the fan and heater as well as update the firmware, allowing for expanded capacity

WIDEST OPERATING RANGE

Of temperature and relative humidity

PRECISION CONTROL

Easy-to-use controls deliver precise variable grain depression to meet requirements of any application

Features

MODULAR DESIGN

Can grow with your business

COMMERCIALLY AVAILABLE COMPONENTS

Easy and quick to find replacement parts, from fans to hardware

Specifications

@ 80 F / 60% RH

Water Removal

190–390 Pints/Day

Current Draw

7.5–15 Amps

Part Number

TR190: 4041620
TR390: 4041630

Dehumidifier Type

Desiccant Dehumidifier

CFM

560–1,030 CFM

Operating Temperature

-4 F Min–104 F Max

Supply Voltage

380–480V, 50–60 Hz

Unit Dimensions

26″ W x 37″ H x 25″ L

Unit Weight

187.4 lb–220.5 lb

Air Filter Dimensions

12″ x 12″ x 2″

Fans

Variable speed EC Motor

Warranty

1 Year
